Railway Traction Systems & Planar Magnetics

Every kilogram added to a high-speed train increases energy consumption, reduces acceleration performance and raises operating costs over a lifespan measured in decades. Yet the demand for onboard electrical power, for climate control, lighting, passenger services, communications, and safety systems - has never been higher. This is the central paradox facing power electronics engineers in modern rail design, and it's driving one of the most significant shifts in transformer technology the industry has seen in a generation.

At the heart of that shift is planar magnetics.

What Is an Auxiliary Power Converter and Why Does It Matter?

Before diving into technology, it's worth understanding the role of the auxiliary power supply (APS) in a modern train. The traction system handles propulsion, hence, converting high-voltage catenary power into the torque that drives the wheels. The APS does everything else. It powers the HVAC systems, interior lighting, passenger information displays, door controls, braking electronics, battery charging systems, and the onboard communications infrastructure that keeps a high-speed train safe and running.

On a modern electric multiple unit (EMU) or high-speed intercity train, the APS typically delivers hundreds of kilowatts of stable, isolated AC and DC output, all drawn from a fluctuating, high-voltage DC or AC bus that can swing dramatically with load changes and regenerative braking events. Doing this reliably, efficiently, and within an ever-shrinking physical envelope is a significant engineering challenge.

The transformer sits at the core of that challenge. It provides galvanic isolation between the high-voltage traction bus and the low-voltage auxiliary circuits, steps voltage levels down to usable ranges, and must do so across an extraordinarily wide operating temperature, vibration, and humidity range. It is, in short, one of the most demanding magnetic applications in any industry and it's precisely the kind of problem that planar technology was engineered to solve.

The Weight Problem in Railway Power Electronics

Weight reduction is not a convenience in rail engineering; it's a commercial and technical imperative. Every additional ton in a high-speed train increases track wear, increases energy consumption, and reduces the payload available for passengers and freight. Modern rail projects target aggressive weight reduction across every subsystem, and the auxiliary power converter is firmly in the crosshairs.

Advanced auxiliary power supply systems using modern power electronics and optimized switching frequencies have demonstrated size and weight reductions of up to 34% compared to conventional systems and that's before planar magnetics are applied to the transformer stage. The industry trend is clear: smaller, lighter, and more efficient, without any compromise on reliability or safety.

The transformer has historically been the hardest component to shrink. Conventional wire-wound transformers are bulky, mechanically complex to manufacture consistently, and thermally constrained. In a railway auxiliary converter, they represent a disproportionate share of the total unit weight and volume. That is precisely where the planar approach changes the equation.

Why Planar Magnetics Are Uniquely Suited to Railway Applications

Planar transformers and inductors replace the hand-wound wire coils of a conventional transformer with flat, etched copper windings on a printed circuit board. The result is a component that is dramatically lower in profile, more consistent in manufacture, and far better at managing thermal load.

For railway auxiliary converter design, the benefits are not theoretical - they are directly measurable:

• Power density up to 3× higher than traditional wire-wound designs, enabling the same power output from a fraction of the volume.
• Efficiency of up to 98-99%, reducing heat generation and the size of the thermal management system required.
• Low profile geometry that integrates natively into the flat, modular power converter assemblies increasingly favored in rail system design.
• Superior thermal conduction through a short heat path from winding to heatsink, critical in enclosed underframe or rooftop-mounted converter cabinets where airflow is limited.
• High repeatability from pre-tooled PCB windings, eliminating the manufacturing variance that plagues hand-wound components in safety-critical applications.
• Low EMI emissions through optimized winding geometry and shielding, directly supporting compliance with the stringent electromagnetic compatibility requirements of the railway environment.

That last point deserves emphasis. The railway environment is electromagnetically hostile. Traction inverters, catenary interference, and regenerative braking transients generate continuous broadband noise. A transformer with poor EMI characteristics creates serious compliance headaches. Planar magnetics, with their tight, controlled winding geometry, perform significantly better in this regard than conventional alternatives.

Meeting the Railway Standards: EN 50155 and Beyond

No component enters a railway vehicle without passing through a rigorous compliance process. The dominant standard governing electronic equipment on rolling stock in Europe, and referenced globally, is EN 50155.

EN 50155 defines requirements across a wide set of performance and environmental parameters, including:

• Input voltage range: Systems must operate across a wide supply variation, typically from 0.6× to 1.4× the nominal bus voltage, demanding that the transformer and converter function correctly across significant input swings.
• Electromagnetic compatibility (EMC): Conducted and radiated emissions must comply with EN 50121-3-2, with strict limits on interference levels from 150 kHz through 1 GHz.
• Environmental robustness: Temperature cycling, humidity, vibration, and shock testing reflect the real operating conditions of rolling stock, from desert heat to alpine cold.
• Insulation and isolation voltage: Galvanic isolation requirements between primary and secondary circuits are strictly defined and must be maintained throughout the product's service life.

Payton’s planar transformer technology complies with international safety standards including full UL certification. With a wide operating power range from 5W to 300kW and operating frequencies up to 2.5 MHz, components are engineered with the performance headroom that demanding railway applications require.

Planar Magnetics in the Auxiliary Converter Stack

Understanding how planar magnetics fit into a modern auxiliary power converter requires a brief look at the converter architecture itself.

The DC Bus Interface Stage

In a modern high-speed train, the auxiliary power converter typically receives a high-voltage DC input from the traction bus, often in the 750V to 3,000V range depending on the rail system. The first stage of the converter filters and conditions this input, and the transformer in this stage must handle significant voltage stress while providing galvanic isolation. A planar transformer here contributes directly to the reduction of the converter's physical footprint while maintaining the isolation integrity demanded by EN 50155.

The High-Frequency DC-DC Conversion Stage

This is where planar magnetics deliver their most dramatic advantage. High-frequency DC-DC converters (typically LLC resonant or phase-shifted full-bridge topologies) operate at switching frequencies far above what wire-wound designs handle efficiently. Planar transformers are optimized for exactly these frequencies, from 20 kHz up to 2.5 MHz, enabling converter designers to reduce passive component values, shrink filter stages, and achieve the high-power density that modern rail systems demand.

The research from Virginia Tech's Center for Power Electronics Systems demonstrated a rail-grade DC-DC converter using planar magnetics in a six-layer PCB winding achieving a peak efficiency of 95.8% with a power density of 195 W/in³,  in a quarter-brick form factor. For a rail application, that level of integration is transformative.

The Output Filtering and Isolation Stage

At the output stage, planar inductors contribute to compact, low-profile EMI filtering assemblies that help the converter meet the conducted emissions limits of EN 50121-3-2. Integrated planar magnetics, where multiple magnetic functions are combined into a single assembly, can reduce component count in this stage significantly, simplifying the converter layout and improving long-term reliability.

The Thermal Advantage in Enclosed Railway Environments

Thermal management in a railway auxiliary converter is not straightforward. Converters are typically mounted in sealed cabinets under the train floor or on the roof: environments with limited airflow, wide ambient temperature swings, and significant thermal mass. The transformer is often the hottest component in the assembly.

Conventional wire-wound transformers trap heat within their winding structure. Planar transformers are fundamentally different: the flat geometry means the heat path from winding to heatsink is short and direct. Payton Planar’s design is engineered specifically for chassis or heatsink mounting, making it directly compatible with the conduction-cooled thermal management architectures used in railway power electronics. This is not a marginal improvement. It can be the difference between a converter that survives its 30-year service life and one that fails prematurely.

Integration and Customization: From Concept to Certification

One of the less-discussed advantages of planar magnetics in railway applications is the benefit they offer during the design and certification process. Because planar transformer windings are etched onto PCBs using standard photolithographic processes, they offer exceptional repeatability from unit to unit. Every transformer that leaves the production line is electrically identical to the design that passed certification, a quality assurance advantage that wire-wound designs simply cannot match.

Payton's engineering team works with railway system integrators from concept through prototype to production, offering custom planar transformer and inductor solutions designed to the specific voltage, power, frequency, and environmental requirements of the target application. For a sector where custom power converter designs are the norm and certification timelines are long, having a magnetics partner with deep application expertise is a material advantage.

Conclusion: The Lighter, Smarter Power Converter Is Here

The pressure on railway engineers to reduce weight, improve efficiency, and shrink converter footprints is not easing, it's accelerating. New high-speed lines, next-generation EMUs, and the electrification of former diesel routes are all driving demand for auxiliary power converters that do more with less. Planar magnetics, with their high power density, superior thermal performance, low EMI, and manufacturing consistency, are uniquely positioned to meet that demand.

The key takeaways are clear: planar transformers reduce APS weight and volume without sacrificing efficiency or reliability, they are inherently compatible with the high-frequency switching topologies that dominate modern rail power converter design, and they support EN 50155 compliance in both electrical performance and EMC characteristics.
